CHD Dissolver
It is widely used in coating, dyestuff, pigment, ink, paper, plastic, rubber, adhesive, sealant and other chemical industries, as well as other industries that need liquid-liquid and liquid-solid material mixing.
It is used for pre dispersion and mixing of various materials.
It is widely used in coating, dyestuff, pigment, ink, paper, plastic, rubber, adhesive, sealant and other chemical industries, as well as other industries that need liquid-liquid and liquid-solid material mixing.
Technical data sheets:
Type | CHD5.5 | CHD7.5 | CHD11 | CHD15 | CHD18.5 | CHD22 | CHD30 |
Power (kw) | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 |
Roation speed (rpm) | 0 - 1450 | 0-1450 | 0-1450 | 0-1450 | |||
Lift travel (mm) | 0 - 900 | 0 - 1100 | 0 - 1000 | 0 -1200 | |||
Center distance | 600 | 1000 | 1000 | 1000 | |||
Workingn capacity(L) | 400-600 | 500-700 | 600-800 | 700-1000 | 800-1200 | 1000-1500 | |
Weight(kg) | 500 | 600 | 700 | 1500 | 1550 | 1600 | 1700 |
Shape size (LxWxH) mm | 1800X650X1750 | 2100X900X2200 | 2100X1100X2100 | 2200X1000X2100 | |||
Type | CHD37 | CHD45 | CHD55 | CHD75 | CHD90 | CHD110 | CHD132 | CHD160 |
Power (kw) | 37 | 45 | 55 | 75 | 90 | 110 | 130 | 160 |
Roation speed (rpm) | 0-1450 | 0-1000 | 0-900 | 0-850 | ||||
Lift travel (mm) | 0 - 1200 | 0-1600 | 0-2200 | 0-2600 | ||||
Center distance | 1200 | 1500 | 1700 | 1850 | ||||
Workingn capacity(L) | 800-2000 | 2500-4500 | 5000 - 6000 | 7000 | ||||
Weight(kg) | 1800 | 2100 | 2500 | 2600 | 2700 | 4500 | 4600 | 5400 |
Shape size (LxWxH) mm | 2300X1100X2200 | 2700X1400X2600 | 3000X 1600X3300 | 3200x1700x3400 | ||||
